Description
Product Description：
Co2 laser marking machine is widely applied to shoes, clothing, packaging, advertising, tobacco, food, medicine and other industries.
Can be widely used for marking on all kinds of nonmetal material,such as Paper, PVC, rubber, wood, ceramics, plastic, leather, fabric surface marking.
| Model Type | MK-20S |
| laser power | 20W |
| Marking area | 100*100/175*175/200*200/300*300mm |
| Laser type | Co2 metal tube |
| Laser source | DAVI |
| Laser repetition frequency | ≤50KHZ |
| Marking speed | 8000mm/s |
| Laser waver-length | 10.6um |
| Marking depth | 0.01mm---0.3mm |
| Min. Line width | 0.015mm |
| Min.character size | 0.4mm |
| Repetition accuracy | ±0.01mm |
| Cooling mode | Air cooling or water cooling |
| Total power consumed | ≤2KW |
| Power supply | 220V/380V(50-60HZ) |
| Suction machines | optional |
 |
LASER SOURCE
We use Chinese famousbrand Max laser source. |
 |
JCZ CONTROL BOARD
Ezcad genuine products, user-friendlyinterface, functional diversity, highstability, high precision. |
 |
THE CONTROL SOFTWARE 1. Powerful editing function. 2. Friendly interface. 3. Easy to use. 4. Support Microsoft Windows XP, VISTA, Win7, Win10 system. E 0 5. Support ai, dxf, dst,plt, bmp,jpg, gif, tga, png, tif and other file formats. 6. Support for TrueType fonts, single line fonts (JSF), SHX fonts, dotmatrix fonts (DMF),1D bar codes and 2D bar codes. Flexible variabletext processing, changing text in real time during processing, can d-irectly read and write text files, SQL databases and Excel file. |
 |
WORKING PLATFORM
Alumina working platform andimported precise beeline device.Flexibility mesa have multiplescrew holes, convenient andcustom installation, special fixture industry platform. |
 |
FOOT SWITCH
It can control the laser on and off.
|
|
|
GOGGLES Can protect eyes from laserwave 1 064nm, let the operatemore safe. |
Applicable Materials:
This Co2 Laser Marker Machines can be used in wood, paper,
leather, cloth. Plexiglass, epoxy,
acrylic, plastic,
ucsaturated polyester resin and other non-metal materials
Applicable Industry:
This series Co2 Laser Markers Machine is widely used in leather, food,
beverage, cloth, electronic, meter, communication instruments,
package and other industries,
can be combined with streamline for online marking.
